Closed System for Media Bottles

Specifications of matching media bottle: 250 mL 500 mL 1000 mL 2000 mL
Type of tube connector: MPC connector  FLL connector  Heat-sealing Port
Specifications of matching tubing: Two-port  Three-port
Packaging: Double-layer outer medical packaging
Get Quotation
Introduction
Product Information
Order Information
Recommended Products

Introduction

Product Information

In the industrial production of biological products, reducing the potential risk of contamination during processes such as liquid transfer and sampling is crucial. Pairing media bottles with sterile transfer caps and tubing systems can effectively prevent contamination issues associated with open operations.
Jet Biofil has introduced Closed System for media bottles, made from USP Class VI-compliant materials, manufactured in GMP-standard cleanrooms. Products have extremely low extractable levels and excellent biosafety, suitable for fluid supplementation and low-temperature storage during the processes of cell & gene therapy, antibody and vaccine biopharmaceutical R&D. They enable fully enclosed aseptic liquid transfer, minimizing contamination risk to the greatest extent.

Customization Service

All Close System Solutions can be customized accordingly



Features

* Crafted by materials comply with the USP Class VI standards with extremely low extractable levels and excellent biosafety
* Injection molded transfer cap combines pinch clamp on inlet/outlet tubing to reduce the risk of leaks and residue
* Inner tube can be extended to the bottom to ensure complete transfer
* 0.22µm PTFE syringe filter balances the internal and external pressure during liquid transfer while maintaining sterility
* Multiple tubing types and connectors are available to meet various pipeline connection requirements
* Working temperature range: -80~60℃
* Sterilized by irradiation, SAL 10-6; DNase/RNase-free, non-pyrogenic, non-cytotoxic

Material

* Bottle (PETG) Bottle cap (HDPE) Inner tube (PTFE) Outer thermoplastic tube (TPE) FLL connector (PP)/Male MPC connector (PC) Filter housing (PP) Filter membrane(PTFE)
* Conforming to USP Class VI standards

Product Information

Closed System for Media Bottles

Brochure

Closed System for Media Bottles

Download File
Closed System Series for Aseptic Transfers

Brochure

Closed System Series for Aseptic Transfers

Download File
Jet Biofil ENG Catalogue 2025

Catalogue

Jet Biofil ENG Catalogue 2025

Download File

Order Information

Cat. No. Product Name Tubing Specification Filter Sterile Qty. Per
Bag
Qty. Per
Case
Tubing Type Tubing Dimension Tubing Connector
CSB010250 Closed System for 250 mL Media Bottle Two-port 60 cm, 1/4" ID, 3/8" OD FLL 0.22 μm,PTFE,φ30 mm Y 1 10
CSB011250 Closed System for 250 mL Media Bottle Two-port 60 cm, 1/4" ID, 3/8" OD Heat-Sealing Port 0.22 μm,PTFE,φ30 mm Y 1 10
CSB012250 Closed System for 250 mL Media Bottle Two-port 60 cm, 1/4" ID, 3/8" OD Male MPC 0.22 μm,PTFE,φ30 mm Y 1 10
CSB211250 Closed System for 250 mL Media Bottle Two-port 60 cm, 1/8" ID, 1/4" OD Heat-Sealing Port 0.22 μm,PTFE,φ30 mm Y 1 10
CSB311250 Closed System for 250 mL Media Bottle Two-port 60 cm, 1/4" ID, 7/16" OD Heat-Sealing Port 0.22 μm,PTFE,φ30 mm Y 1 10
CSB020250 Sterile Transfer Cap of 250 mL Media Bottle Two-port 60 cm, 1/4" ID, 3/8" OD FLL 0.22 μm,PTFE,φ30 mm Y 1 10
CSB021250 Sterile Transfer Cap of 250 mL Media Bottle Two-port 60 cm, 1/4" ID, 3/8" OD Heat-Sealing Port 0.22 μm,PTFE,φ30 mm Y 1 10
CSB022250 Sterile Transfer Cap of 250 mL Media Bottle Two-port 60 cm, 1/4" ID, 3/8" OD Male MPC 0.22 μm,PTFE,φ30 mm Y 1 10
CSB110250 Closed System for 250 mL Media Bottle Three-port 60 cm, 1/4" ID, 3/8" OD FLL 0.22 μm,PTFE,φ30 mm Y 1 10
CSB111250 Closed System for 250 mL Media Bottle Three-port 60 cm, 1/4" ID, 3/8" OD Heat-Sealing Port 0.22 μm,PTFE,φ30 mm Y 1 10
CSB120250 Sterile Transfer Cap of 250 mL Media Bottle Three-port 60 cm, 1/4" ID, 3/8" OD FLL 0.22 μm,PTFE,φ30 mm Y 1 10
CSB121250 Sterile Transfer Cap of 250 mL Media Bottle Three-port 60 cm, 1/4" ID, 3/8" OD Heat-Sealing Port 0.22 μm,PTFE,φ30 mm Y 1 10
CSB010500 Closed System for 500 mL Media Bottle Two-port 60 cm, 1/4" ID, 3/8" OD FLL 0.22 μm,PTFE,φ30 mm Y 1 10
CSB011500 Closed System for 500 mL Media Bottle Two-port 60 cm, 1/4" ID, 3/8" OD Heat-Sealing Port 0.22 μm,PTFE,φ30 mm Y 1 10
CSB012500 Closed System for 500 mL Media Bottle Two-port 60 cm, 1/4" ID, 3/8" OD Male MPC 0.22 μm,PTFE,φ30 mm Y 1 10
CSB211500 Closed System for 500 mL Media Bottle Two-port 60 cm, 1/8" ID, 1/4" OD Heat-Sealing Port 0.22 μm,PTFE,φ30 mm Y 1 10
CSB013500 Closed System for 500 mL Media Bottle Two-port 60 cm, 1/4" ID, 7/16" OD Heat-Sealing Port 0.22 μm,PTFE,φ30 mm Y 1 10
CSB020500 Sterile Transfer Cap of 500 mL Media Bottle Two-port 60 cm, 1/4" ID, 3/8" OD FLL 0.22 μm,PTFE,φ30 mm Y 1 10
CSB021500 Sterile Transfer Cap of 500 mL Media Bottle Two-port 60 cm, 1/4" ID, 3/8" OD Heat-Sealing Port 0.22 μm,PTFE,φ30 mm Y 1 10
CSB022500 Sterile Transfer Cap of 500 mL Media Bottle Two-port 60 cm, 1/4" ID, 3/8" OD Male MPC 0.22 μm,PTFE,φ30 mm Y 1 10
CSB110500 Closed System for 500 mL Media Bottle Three-port 60 cm, 1/4" ID, 3/8" OD FLL 0.22 μm,PTFE,φ30 mm Y 1 10
CSB111500 Closed System for 500 mL Media Bottle Three-port 60 cm, 1/4" ID, 3/8" OD Heat-Sealing Port 0.22 μm,PTFE,φ30 mm Y 1 10
CSB120500 Sterile Transfer Cap of 500 mL Media Bottle Three-port 60 cm, 1/4" ID, 3/8" OD FLL 0.22 μm,PTFE,φ30 mm Y 1 10
CSB121500 Sterile Transfer Cap of 500 mL Media Bottle Three-port 60 cm, 1/4" ID, 3/8" OD Heat-Sealing Port 0.22 μm,PTFE,φ30 mm Y 1 10
CSB010001 Closed System for 1000 mL Media Bottle Two-port 60 cm, 1/4" ID, 3/8" OD FLL 0.22 μm,PTFE,φ30 mm Y 1 10
CSB011001 Closed System for 1000 mL Media Bottle Two-port 60 cm, 1/4" ID, 3/8" OD Heat-Sealing Port 0.22 μm,PTFE,φ30 mm Y 1 10
CSB012001 Closed System for 1000 mL Media Bottle Two-port 60 cm, 1/4" ID, 3/8" OD Male MPC 0.22 μm,PTFE,φ30 mm Y 1 10
CSB211001 Closed System for 1000 mL Media Bottle Two-port 60 cm, 1/8" ID, 1/4" OD Heat-Sealing Port 0.22 μm,PTFE,φ30 mm Y 1 10
CSB311001 Closed System for 1000 mL Media Bottle Two-port 60 cm, 1/8" ID, 1/4" OD FLL 0.22 μm,PTFE,φ30 mm Y 1 10
CSB511001 Closed System for 1000 mL Media Bottle Two-port 60 cm, 1/4" ID, 7/16" OD Heat-Sealing Port 0.22 μm,PTFE,φ30 mm Y 1 10
CSB020001 Sterile Transfer Cap of 1000 mL Media Bottle Two-port 60 cm, 1/4" ID, 3/8" OD FLL 0.22 μm,PTFE,φ30 mm Y 1 10
CSB021001 Sterile Transfer Cap of 1000 mL Media Bottle Two-port 60 cm, 1/4" ID, 3/8" OD Heat-Sealing Port 0.22 μm,PTFE,φ30 mm Y 1 10
CSB022001 Sterile Transfer Cap of 1000 mL Media Bottle Two-port 60 cm, 1/4" ID, 3/8" OD Male MPC 0.22 μm,PTFE,φ30 mm Y 1 10
CSB110001 Closed System for 1000 mL Media Bottle Three-port 60 cm, 1/4" ID, 3/8" OD FLL 0.22 μm,PTFE,φ30 mm Y 1 10
CSB111001 Closed System for 1000 mL Media Bottle Three-port 60 cm, 1/4" ID, 3/8" OD Heat-Sealing Port 0.22 μm,PTFE,φ30 mm Y 1 10
CSB120001 Sterile Transfer Cap of 1000 mL Media Bottle Three-port 60 cm, 1/4" ID, 3/8" OD FLL 0.22 μm,PTFE,φ30 mm Y 1 10
CSB121001 Sterile Transfer Cap of 1000 mL Media Bottle Three-port 60 cm, 1/4" ID, 3/8" OD Heat-Sealing Port 0.22 μm,PTFE,φ30 mm Y 1 10
CSB010002 Closed System for 2000 mL Media Bottle Two-port 60 cm, 1/4" ID, 3/8" OD FLL 0.22 μm,PTFE,φ50 mm Y 1 6
CSB011002 Closed System for 2000 mL Media Bottle Two-port 60 cm, 1/4" ID, 3/8" OD Heat-Sealing Port 0.22 μm,PTFE,φ50 mm Y 1 6
CSB012002 Closed System for 2000 mL Media Bottle Two-port 60 cm, 1/4" ID, 3/8" OD Male MPC 0.22 μm,PTFE,φ50 mm Y 1 6
CSB014002 Closed System for 2000 mL Media Bottle Two-port 60 cm, 1/8" ID, 1/4" OD Heat-Sealing Port 0.22 μm,PTFE,φ50 mm Y 1 6
CSB020002 Sterile Transfer Cap of 2000 mL Media Bottle Two-port 60 cm, 1/4" ID, 3/8" OD FLL 0.22 μm,PTFE,φ50 mm Y 1 6
CSB021002 Sterile Transfer Cap of 2000 mL Media Bottle Two-port 60 cm, 1/4" ID, 3/8" OD Heat-Sealing Port 0.22 μm,PTFE,φ50 mm Y 1 6
CSB022002 Sterile Transfer Cap of 2000 mL Media Bottle Two-port 60 cm, 1/4" ID, 3/8" OD Male MPC 0.22 μm,PTFE,φ50 mm Y 1 6
CSB013002 Closed System for 2000 mL Media Bottle Two-port 60 cm, 1/4" ID, 7/16" OD Heat-Sealing Port 0.22 μm,PTFE,φ50 mm Y 1 6

* MLL male Luer connector with plug; MPC male MPC connector with plug
